MAYRC 75V 300A VESCTOOL Waterproof Speed Controller with Watercooling Tube for Wakesurfing Board
MAYRC 75V 300A VESCTOOL Waterproof Speed Controller with Watercooling Tube for Wakesurfing Board
Couldn't load pickup availability
MAYRC 75V 300A VESCTOOL Waterproof Speed Controller with Watercooling Tube for Wakesurfing Board
Specification:
| Model： | MTSPF7.5HK |
| With Aluminum Case： | YES |
| Cont. Current:： | 300A-400A |
| Input Volt.： | 75V |
| Hardware： | Based on V7.5 High voltage |
| Firmware： | Upgradable |
| Software： | VESCTOOL Compatible |
| FOC： | YES; Better than V4.12 |
| Compatible motor： | Sensor or sensorless |
| Weight： | 500g |
Application:
Electric car, ev car, electric surfboard, electric motorcycle, electric foil, hydrofoil, motorized boat rc boat, agv car, go cart, unmanned aerial vehicle, unmanned drone, underwater scooter, efoil, robots, etc.
Set in VESCTOOL:
1：Motor Current Max: ≤300A (According to your motor current)
2：Absolute Maximum Current: 350A (According to your motor current)
3：Battery Current Max: ≤150A (According to your battery discharge current)
You can use default values after "Setup Motors FOC" detection.
The VESC is open source, these values are just for reference based on our engineer experience for your reference.
Notice：
1. Never connect one reclever to two or more V6/V75 based SUPERFOC ESCs or VESCs in an array! Permanent damage may result from Y-PPM wiring.
2. Only connect CAN L and CAN H ! GND pins and 5V should never be connected in a V6/V75 based SUPERFOC ESCs or VESC array.
